前言

因为上次写的脚本，需要先将交换机输出的信息先保存至文件中，再使用正则表达式处理文本输出到表格中，能不能直接就将交换机输出的信息处理到表格，答案肯定是可以的，而且上次的脚本H3C设备没有模块SN的信息，也是一个漏洞，接下来，让我们来改进一下（当然，还是使用AI生成）

前期准备

  • Python 第三方库
    • netmiko 连接交换机
    • re 正则表达式
    • pandas 处理表格
  • Excel文件，放设备信息，需要两列，dname一列，ip一列
    • devices.xls
      • image.png | 500

华为

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
import pandas as pd
from netmiko import ConnectHandler
import re

# 读取设备信息
device_info = pd.read_excel('devices.xls')  # 假设Excel文件名为devices.xlsx

# 创建一个空字典以存储结果
results = {}

for index, row in device_info.iterrows():
    device = {
        'device_type': 'huawei',  # 改为使用telnet连接华为设备huawei_telnet
        'ip': row['ip'],
        'username': 'username',
        'password': 'password',
        'port': 22,  # 改为telnet默认端口23
        'timeout': 30,
        'global_delay_factor': 3,
        'fast_cli': False,
        'session_log': 'netmiko_session.log'
    }

    try:
        # 连接到交换机
        client = ConnectHandler(**device)

        # 取消分页以获取完整输出
        client.send_command("screen-length 0 temporary")

        # 获取设备SN信息
        sn_command = 'dis device manufacture-info'
        sn_output = client.send_command(sn_command)
        sn_match = re.search(r'(\d+)\s+-\s+(\S+)', sn_output)
        device_sn = sn_match.group(2) if sn_match else '未找到序列号'

        # 获取端口模块信息
        port_command = 'dis transceiver'
        port_output = client.send_command(port_command, delay_factor=3)

        # 解析端口模块信息并拆分成行
        port_lines = port_output.splitlines()
        port_info_list = []

        current_port = None

        for line in port_lines:
            if "transceiver information" in line:
                if current_port is not None:
                    port_info_list.append(current_port)
                current_port = {'Port': line.split()[0]}
            elif "Transceiver Type" in line:
                current_port['Transceiver Type'] = line.split(":")[1].strip()
            elif "Vendor Name" in line:
                current_port['Vendor Name'] = line.split(":")[1].strip()
            elif "Manu. Serial Number" in line:
                current_port['Manu. Serial Number'] = line.split(":")[1].strip()
            elif "Transfer Distance(m)" in line:  # 添加此行以提取传输距离信息
                current_port['Transfer Distance(m)'] = line.split(":")[1].strip()

        if current_port is not None:
            port_info_list.append(current_port)

        # 将结果存储在字典中，以设备名为键
        results[row['dname']] = {
            'Device Serial Number': device_sn,
            'Port Info': pd.DataFrame(port_info_list)
        }

    except Exception as e:
        print(f"连接到 {row['dname']} ({row['ip']}) 时出错: {e}")

    finally:
        if 'client' in locals():
            client.disconnect()

# 保存结果到Excel文件，每个设备一个工作表
with pd.ExcelWriter('device_info_results.xlsx') as writer:
    for device_name, data in results.items():
        data['Port Info'].to_excel(writer, sheet_name=device_name, index=False)

print("设备信息已保存至 Excel 文件。")

H3C

华三的脚本是先采集端口模块的信息，再读取port信息为变量，采集模块SN

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
import pandas as pd
from netmiko import ConnectHandler

# 读取设备信息
device_info = pd.read_excel('devices_h3c.xls')  # 假设Excel文件名为devices.xlsx

# 创建一个空字典以存储结果
results = {}

for index, row in device_info.iterrows():
    device = {
        'device_type': 'hp_comware',
        'username': 'username',  # 替换为您的用户名
        'password': 'password',  # 替换为您的密码
        'ip': row['ip'],
        'port': 22,
        'timeout': 30,
        'global_delay_factor': 2,
        'fast_cli': False,
        'session_log': 'netmiko_session.log'
    }

    try:
        # 连接到交换机
        client = ConnectHandler(**device)

        # 取消分页以获取完整输出
        client.send_command("screen-length disable")

        # 获取端口模块信息
        port_command = 'dis transceiver interface'
        port_output = client.send_command(port_command)

        # 解析端口模块信息并拆分成行
        port_lines = port_output.splitlines()
        port_info_list = []

        current_port = None

        for line in port_lines:
            if "transceiver information" in line:
                if current_port is not None:
                    port_info_list.append(current_port)
                current_port = {'Port': line.split()[0]}
            elif "Transceiver Type" in line:
                current_port['Transceiver Type'] = line.split(":")[1].strip()
            elif "Connector Type" in line:
                current_port['Connector Type'] = line.split(":")[1].strip()
            elif "Wavelength(nm)" in line:
                current_port['Wavelength(nm)'] = line.split(":")[1].strip()
            elif "Transfer Distance(m)" in line:
                current_port['Transfer Distance(m)'] = line.split(":")[1].strip()
            elif "Transfer Distance(km)" in line:
                current_port['Transfer Distance(km)'] = line.split(":")[1].strip()
            elif "Vendor Name" in line:
                current_port['Vendor Name'] = line.split(":")[1].strip()
            elif "Ordering Name" in line:
                current_port['Ordering Name'] = line.split(":")[1].strip()

        if current_port is not None:
            port_info_list.append(current_port)

        # 获取制造序列号信息
        for port in port_info_list:
            if 'Transceiver Type' in port:  # 仅对有模块的端口查找SN
                sn_command = f'dis transceiver manuinfo interface {port["Port"]}'
                sn_output = client.send_command(sn_command)

                # 将整个输出结果添加到当前端口信息中
                port['Manufacture Info'] = sn_output

        # 将结果存储在字典中，以设备名为键
        results[row['dname']] = pd.DataFrame(port_info_list)

    except Exception as e:
        print(f"连接到 {row['dname']} ({row['ip']}) 时出错: {e}")

    finally:
        if 'client' in locals():
            client.disconnect()

# 保存结果到Excel文件，每个设备一个工作表
with pd.ExcelWriter('h3c_device_info_results.xlsx') as writer:
    for device_name, df in results.items():
        df.to_excel(writer, sheet_name=device_name, index=False)

print("H3C交换机模块信息及SN已保存至 Excel 文件。")

效果

华为

  • 每一个交换机，单独一个sheet
    image.png | 500

H3C

  • 和上面的逻辑一样，只不过H3C的会采集出来空端口
    image.png | 500
